艾博康編碼ASTX-H11-26.000MHZ-T TCXO振蕩器,非常適合用于移動通信設備
來源：http://www.theqj.cn 作者：ysi 2022年07月27
Abracon晶振公司是一家極其具備高度創新能力的杰出制造商,自成立至今,研發新型的產品數不勝舉,每一款產品推出必成為時下的經典產品,就連帶新發布的IoT優化晶體系列專門設計用于解決越來越多的低功耗趨勢，從而導致設計人員在整個行業中面臨的跨導值下降。這些IoT優化的晶體與業界最低的gm_critical設計兼容。對于50MHz操作，ABM8W / ABM10W / ABM11W / ABM12W系列保證在gm_critical低至3.55mA / V的條件下工作。艾博康編碼ASTX-H11-26.000MHZ-T TCXO振蕩器,非常適合用于移動通信設備
ABS06W / ABS07W系列保證工作在1.1μA/ V以上的gm_critical。鑒于許多常見的MCU，例如ST Micro系列STM32M4F / STM32F3 / STM32F4 / STM32L4，其在32.768kHz操作下在1μA/ V附近顯示gm_critical，使用非常低的鍍層晶體的關鍵性是巨大的。 Abracon的新型IoT優化貼片晶振系列目前在世界上提供了最低的負載電容選項。
| ASFL1-4.000MHZ-EK-T | Abracon晶振 | ASFL1 | XO (Standard) | 4MHz | 3.3V | -20°C ~ 70°C |
| ASFL1-50.000MHZ-EK-T | Abracon晶振 | ASFL1 | XO (Standard) | 50MHz | 3.3V | -20°C ~ 70°C |
| ASFL1-48.000MHZ-EK-T | Abracon晶振 | ASFL1 | XO (Standard) | 48MHz | 3.3V | -20°C ~ 70°C |
| ASFL3-24.000MHZ-EK-T | Abracon晶振 | ASFL3 | XO (Standard) | 24MHz | 1.8V | -20°C ~ 70°C |
| ASFL1-14.31818MHZ-EK-T | Abracon晶振 | ASFL1 | XO (Standard) | 14.31818MHz | 3.3V | -20°C ~ 70°C |
| ASFL1-16.000MHZ-EK-T | Abracon晶振 | ASFL1 | XO (Standard) | 16MHz | 3.3V | -20°C ~ 70°C |
| ASFL1-20.000MHZ-EK-T | Abracon晶振 | ASFL1 | XO (Standard) | 20MHz | 3.3V | -20°C ~ 70°C |
| ASFLK-32.768KHZ-LJT | Abracon晶振 | ASFLK | XO (Standard) | 32.768kHz | 3.3V | -40°C ~ 85°C |
| ASEK1-32.768KHZ-LRT | Abracon晶振 | ASEK | XO (Standard) | 32.768kHz | 2.5V | -40°C ~ 85°C |
| ASAK-32.768KHZ-LRS-T | Abracon晶振 | ASAK | XO (Standard) | 32.768kHz | 3.3V | -40°C ~ 85°C |
| ASAK1-32.768KHZ-LRS-T | Abracon晶振 | ASAK | XO (Standard) | 32.768kHz | 2.5V | -40°C ~ 85°C |
| ASAK2-32.768KHZ-LRS-T | Abracon晶振 | ASAK | XO (Standard) | 32.768kHz | 1.8V | -40°C ~ 85°C |
| ASV-27.000MHZ-E-T | Abracon晶振 | ASV | XO (Standard) | 27MHz | 3.3V | -20°C ~ 70°C |
| ASV-60.000MHZ-E-T | Abracon晶振 | ASV | XO (Standard) | 60MHz | 3.3V | -20°C ~ 70°C |
| ASV-18.432MHZ-E-T | Abracon晶振 | ASV | XO (Standard) | 18.432MHz | 3.3V | -20°C ~ 70°C |
| ASV-29.4912MHZ-E-T | Abracon晶振 | ASV | XO (Standard) | 29.4912MHz | 3.3V | -20°C ~ 70°C |
| ASV-8.000MHZ-E-T | Abracon晶振 | ASV | XO (Standard) | 8MHz | 3.3V | -20°C ~ 70°C |
| ASV-24.000MHZ-E-T | Abracon晶振 | ASV | XO (Standard) | 24MHz | 3.3V | -20°C ~ 70°C |
| ASV-16.384MHZ-E-T | Abracon晶振 | ASV | XO (Standard) | 16.384MHz | 3.3V | -20°C ~ 70°C |
| ASFL1-27.000MHZ-EK-T | Abracon晶振 | ASFL1 | XO (Standard) | 27MHz | 3.3V | -20°C ~ 70°C |
| ASFL1-50.000MHZ-EC-T | Abracon晶振 | ASFL1 | XO (Standard) | 50MHz | 3.3V | -20°C ~ 70°C |
| ASV-48.000MHZ-E-T | Abracon晶振 | ASV | XO (Standard) | 48MHz | 3.3V | -20°C ~ 70°C |
| ASE3-25.000MHZ-EK-T | Abracon晶振 | ASE3 | XO (Standard) | 25MHz | 1.8V | -20°C ~ 70°C |
| ASV-50.000MHZ-EJ-T | Abracon晶振 | ASV | XO (Standard) | 50MHz | 3.3V | -20°C ~ 70°C |
| ASV-11.0592MHZ-E-T | Abracon晶振 | ASV | XO (Standard) | 11.0592MHz | 3.3V | -20°C ~ 70°C |
| ASV-50.000MHZ-E-T | Abracon晶振 | ASV | XO (Standard) | 50MHz | 3.3V | -20°C ~ 70°C |
| ASV-3.6864MHZ-E-T | Abracon晶振 | ASV | XO (Standard) | 3.6864MHz | 3.3V | -20°C ~ 70°C |
| ASE3-25.000MHZ-LC-T | Abracon晶振 | ASE3 | XO (Standard) | 25MHz | 1.8V | -40°C ~ 85°C |
| ASFL1-12.288MHZ-EC-T | Abracon晶振 | ASFL1 | XO (Standard) | 12.288MHz | 3.3V | -20°C ~ 70°C |
| ASFL1-24.000MHZ-EC-T | Abracon晶振 | ASFL1 | XO (Standard) | 24MHz | 3.3V | -20°C ~ 70°C |
| ASFL1-20.000MHZ-EC-T | Abracon晶振 | ASFL1 | XO (Standard) | 20MHz | 3.3V | -20°C ~ 70°C |
| ASFL1-48.000MHZ-EC-T | Abracon晶振 | ASFL1 | XO (Standard) | 48MHz | 3.3V | -20°C ~ 70°C |
| ASFL1-1.8432MHZ-L-T | Abracon晶振 | ASFL1 | XO (Standard) | 1.8432MHz | 3.3V | -40°C ~ 85°C |
| ASFL1-30.000MHZ-EC-T | Abracon晶振 | ASFL1 | XO (Standard) | 30MHz | 3.3V | -20°C ~ 70°C |
| ASFL1-12.288MHZ-L-T | Abracon晶振 | ASFL1 | XO (Standard) | 12.288MHz | 3.3V | -40°C ~ 85°C |
| ASFL1-24.000MHZ-L-T | Abracon晶振 | ASFL1 | XO (Standard) | 24MHz | 3.3V | -40°C ~ 85°C |
| ASE-48.000MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 48MHz | 3.3V | -40°C ~ 85°C |
| ASFL1-20.000MHZ-L-T | Abracon晶振 | ASFL1 | XO (Standard) | 20MHz | 3.3V | -40°C ~ 85°C |
| ASDK2-32.768KHZ-LR-T3 | Abracon晶振 | ASDK | XO (Standard) | 32.768kHz | 1.8V | -40°C ~ 85°C |
In addition to the standard frequency [non-factory-configurable] ClearClockTM solutions, Abracon has developed the ASGTX5 series to address the Stratum-IV clocking systems that have an all-inclusive total stability requirement of ±32ppm maximum. This requirement is inclusive of initial set-tolerance, shift through reflow, frequency pulling and pushing, frequency stability over -40?C to +85?C, and long-term aging (20 years).
除了標準頻率[非工廠可配置]ClearClockTM解決方案，Abracon有源晶振還有研發了ASGTX5系列，以解決Stratum-IV全包式時鐘系統總穩定性要求最大±32ppm。這個要求包括初始集容差、移位通過回流，頻率推拉，頻率穩定性超過-40?C到+85?C，并且是長期的老化(20年)。
| ASE-25.000MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 25MHz | 3.3V | -40°C ~ 85°C |
| ASE-50.000MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 50MHz | 3.3V | -40°C ~ 85°C |
| ASE-24.000MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 24MHz | 3.3V | -40°C ~ 85°C |
| ASE-12.000MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 12MHz | 3.3V | -40°C ~ 85°C |
| ASE-1.8432MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 1.8432MHz | 3.3V | -40°C ~ 85°C |
| ASE-8.000MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 8MHz | 3.3V | -40°C ~ 85°C |
| ASFL1-66.666MHZ-EC-T | Abracon晶振 | ASFL1 | XO (Standard) | 66.666MHz | 3.3V | -20°C ~ 70°C |
| ASE-12.000MHZ-ET | Abracon晶振 | ASE | XO (Standard) | 12MHz | 3.3V | -20°C ~ 70°C |
| ASE-24.000MHZ-ET | Abracon晶振 | ASE | XO (Standard) | 24MHz | 3.3V | -20°C ~ 70°C |
| ASE-50.000MHZ-ET | Abracon晶振 | ASE | XO (Standard) | 50MHz | 3.3V | -20°C ~ 70°C |
| ASE2-22.000MHZ-ET | Abracon晶振 | ASE2 | XO (Standard) | 22MHz | 2.5V | -20°C ~ 70°C |
| ASEK-32.768KHZ-LRT | Abracon晶振 | ASEK | XO (Standard) | 32.768kHz | 3.3V | -40°C ~ 85°C |
| ASE-24.576MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 24.576MHz | 3.3V | -40°C ~ 85°C |
| ASE-11.0592MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 11.0592MHz | 3.3V | -40°C ~ 85°C |
| ASE-33.333MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 33.333MHz | 3.3V | -40°C ~ 85°C |
| ASE3-25.000MHZ-KT | Abracon晶振 | ASE3 | XO (Standard) | 25MHz | 1.8V | -10°C ~ 70°C |
| ASE3-50.000MHZ-KT | Abracon晶振 | ASE3 | XO (Standard) | 50MHz | 1.8V | -10°C ~ 70°C |
| ASE-14.7456MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 14.7456MHz | 3.3V | -40°C ~ 85°C |
| ASE-18.432MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 18.432MHz | 3.3V | -40°C ~ 85°C |
| ASE-20.000MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 20MHz | 3.3V | -40°C ~ 85°C |
The ASGTX5 temperature-compensated crystal oscillator (TCXO) solution meets this stringent requirement at any carrier frequency between 15.0MHz and 2.1GHz. However, to achieve that precision,this solution has slightly worse RMS jitter than its third overtone ClearClockTM counterparts. For instance, it exhibits < 350fs typical RMS jitter at 156.25MHz carrier.
ASGTX5溫度補償晶體振蕩器(TCXO)溶液滿足這一嚴格要求在15.0MHz和2.1GHz之間的任何載頻要求。然而，為了達到這種精確度，這個解決方案有略差的RMS抖動比它的第三泛音ClearClockTM對應。例如,它在156.25MHz載波下表現出< 350fs的典型RMS抖動。
| ASE-27.000MHZ-LC-T | Abracon晶振 | ASE | XO (Standard) | 27MHz | 3.3V | -40°C ~ 85°C |
| ASFL1-66.666MHZ-L-T | Abracon晶振 | ASFL1 | XO (Standard) | 66.666MHz | 3.3V | -40°C ~ 85°C |
| ASV-33.000MHZ-EJ-T | Abracon晶振 | ASV | XO (Standard) | 33MHz | 3.3V | -20°C ~ 70°C |
| ASV-7.3728MHZ-EJ-T | Abracon晶振 | ASV | XO (Standard) | 7.3728MHz | 3.3V | -20°C ~ 70°C |
| ASV-12.000MHZ-EJ-T | Abracon晶振 | ASV | XO (Standard) | 12MHz | 3.3V | -20°C ~ 70°C |
| ASV-3.6864MHZ-EJ-T | Abracon晶振 | ASV | XO (Standard) | 3.6864MHz | 3.3V | -20°C ~ 70°C |
| ASV-24.000MHZ-EJ-T | Abracon晶振 | ASV | XO (Standard) | 24MHz | 3.3V | -20°C ~ 70°C |
| ASV-25.000MHZ-EJ-T | Abracon晶振 | ASV | XO (Standard) | 25MHz | 3.3V | -20°C ~ 70°C |
| ASV-30.000MHZ-EJ-T | Abracon晶振 | ASV | XO (Standard) | 30MHz | 3.3V | -20°C ~ 70°C |
| ASV-10.000MHZ-EJ-T | Abracon晶振 | ASV | XO (Standard) | 10MHz | 3.3V | -20°C ~ 70°C |
| ASV-16.384MHZ-EJ-T | Abracon晶振 | ASV | XO (Standard) | 16.384MHz | 3.3V | -20°C ~ 70°C |
| ASCO-12.000MHZ-EK-T3 | Abracon晶振 | ASCO | XO (Standard) | 12MHz | 3.3V | -20°C ~ 70°C |
| ASCO-24.000MHZ-EK-T3 | Abracon晶振 | ASCO | XO (Standard) | 24MHz | 3.3V | -20°C ~ 70°C |
| ASCO-8.000MHZ-EK-T3 | Abracon晶振 | ASCO | XO (Standard) | 8MHz | 3.3V | -20°C ~ 70°C |
| ASFL3-16.000MHZ-EK-T | Abracon晶振 | ASFL3 | XO (Standard) | 16MHz | 1.8V | -20°C ~ 70°C |
| ASEK2-32.768KHZ-LRT | Abracon晶振 | ASEK | XO (Standard) | 32.768kHz | 1.8V | -40°C ~ 85°C |
| ASFL1-14.7456MHZ-EK-T | Abracon晶振 | ASFL1 | XO (Standard) | 14.7456MHz | 3.3V | -20°C ~ 70°C |
| ASDK-32.768KHZ-LRT | Abracon晶振 | ASDK | XO (Standard) | 32.768kHz | 3.3V | -40°C ~ 85°C |
| ASDK2-32.768KHZ-LRT | Abracon晶振 | ASDK | XO (Standard) | 32.768kHz | 1.8V | -40°C ~ 85°C |
| ASFL1-25.000MHZ-EK-T | Abracon晶振 | ASFL1 | XO (Standard) | 25MHz | 3.3V | -20°C ~ 70°C |
ASGTX5 TCXO振蕩器除了標準的LVDS、LVPECL外，還具有CML差分輸出格式和HCSL祭。需要CML輸出類型的系統架構當然可以受益于ASGTX5系列。
雖然ASGTX5規定了在-40?C到+85?C上保證的最大誤差為±3.0 ppm在這個擴展的工作溫度范圍內，設備通常保持優于±1.0 PPM的精度。下面的圖9概述了ASGTX5設備在156.25MHz的溫度穩定性性能母艦。
